一、型号意义：
|
| 二、选型参数： |
|
序 号 No. |
型号
Type |
流量 Capacity (m3/h) |
扬程 Head (m) |
效率 Eff. (%) |
转速 Speed (r/min) |
电机 功率 Power (kw) |
必须汽 蚀余量 (NPSH)r (m) |
重量 Weight (kg) |
| 141 | KYL100-100 |
70 100 130 |
13.6 12.5 11 |
66 76 75 |
2900 | 5.5 | 4.5 | 220 |
| 142 | KYL100-100A |
63 89 116 |
11 10 8.8 |
64 74 72 |
2900 | 22 | 4.5 | 100 |
| 143 | KYL100-125 |
70 100 130 |
23.5 20 24 |
70 76 65 |
2900 | 11 | 4.5 | 174 |
| 144 | KYL100-125A |
63 89 116 |
19 16 11 |
68 74 63 |
2900 | 7.5 | 4.5 | 125 |
| 145 | KYL100-160 |
70 100 130 |
36.5 32 24 |
70 76 65 |
2900 | 15 | 4.5 | 185 |
| 146 | KYL100-160A |
65 94 121 |
32 28 21 |
68 74 67 |
2900 | 11 | 4.5 | 175 |
| 147 | KYL100-160B |
61 87 112 |
27 24 18 |
66 72 64 |
2900 | 7.5 | 4.5 | 125 |
| 148 | KYL100-200 |
70 100 130 |
54 50 42 |
65 74 73 |
2900 | 22 | 4 | 250 |
| 149 | KYL100-200A |
65 94 121 |
47.5 44 37 |
64 73 72 |
2900 | 18.5 | 4 | 210 |
| 150 | KYL100-200B |
61 87 113 |
41 38 32 |
62 71 69 |
2900 | 15 | 4 | 188 |
| 151 | KYL100-250 |
70 100 130 |
87 80 68 |
62 69 68 |
2900 | 37 | 4 | 350 |
| 152 | KYL100-250A |
65 94 121 |
76 70 59.5 |
61 68 67 |
2900 | 30 | 4 | 330 |
| 153 | KYL100-250B |
61 87 113 |
65 60 51 |
59 68 66 |
2900 | 22 | 4 | 270 |
| 154 | KYL100-315 |
70 100 130 |
132 125 114 |
55 66 67 |
2900 | 75 | 4 | 680 |
| 155 | KYL100-315A |
67 95 123 |
119 113 103 |
55 66 67 |
2900 | 55 | 4 | 540 |
| 156 | KYL100-315B |
63 90 117 |
106 101 92 |
54 65 66 |
2900 | 45 | 4 | 440 |
| 157 | KYL100-350 |
70 100 130 |
156 150 148 |
42 57 70 |
2900 | 90 | 4 | 740 |
| 158 | KYL100-350A |
64 88 113 |
148 142 134 |
43 58 72 |
2900 | 75 | 4 | 650 |
| 159 | KYL100-350B |
56 80 104 |
140 135 125 |
45 60 73 |
2900 | 55 | 4 | 510 |
